Putting in place

It is not recommended to install your dryer

on a carpeted floor. If this cannot be

avoided, provide proper air circulation

underneath the appliance.

LEVELLING (FIG. 5)

The tumble dryer has to be in a

horizontal position, not sloping.

Levelling is essential to ensure proper

operation of the machine.

Adjust the feet using a spanner to ensure

that the dryer is level and check with a

spirit level (maximum angle 1.5°, that is

less than 1 cm).

ENVIRONMENT

Your tumble dryer releases hot air.

If it is placed near another appliance or

next to a cabinet, a minimum 1 cm space

should be provided in between to assist

ventilation.

ELECTRICAL CONNECTION (Fig. 6)

The electrical installation must be made in

accordance to the standard.

Do not connect the appliance through an

extension but plug it directly into an

electrical socket.

In case of supply cord defect call for a

skilled person to replace it because

special tools are required.

Replacing the electric lead

WARNING: In the interests of safety,

the electrical supply lead should ONLY

be replaced by the manufacturer’s

after-sales staff or a similarly qualified

person.

We cannot be held liable for any

damage and possible repercussions

resulting from a faulty earthing, or the

absence of earthing of the appliance.

DOOR OPENING

Lift the cover to reach the drum.

Cover safety device : It is only possible

to switch on if the cover is properly

closed.

LAUNDRY LOADING

After your clothes have been washed and

spun, put the laundry loosely in the drum

without folding and squeezing.

Any items which have been treated

with a chemical stain remover or an

aerosol, must not be put into the

tumble dryer : inflammable products,

danger of explosion

If your laundry needs such treatment,

it must

absolutely

be done before

washing.

LINT FILTER CLEANING (fig. 7)

WARNING : After every drying process it

is necessery to clear the lint deposits on

the filter.

Do not clean it with water.

The lint filter, on the lefthand side of the

drum, has to be cleaned without any

water after every cycle. Never rinse it

with water at the end of the programme.

➀ Remove the filter by pulling it upwards

➁ Once the thin layer of lint has been

removed from the filter, put it back into

position by pushing it firmly downwards.

At the end of the programme, your

appliance stops at the position “STOP”.

The lamp ‘’filter cleaning’’ lights up to

remind you that you have to clean the filter.

The lamp ‘’on’’ goes out.

Using Selecting a Drying programme

SWITCHING ON

• Check that the electricity supply cable is

properly connected.

• Selecting a drying-time starts the dryer.

The lamp “on” light will go on.

Safety device: the machine can only be

switched on if the lid is properly closed.

SELECTING OF THE LAUNDRY

see picture 8

➀➀

COTTON : For household linen,

towels and cotton clothes and underwear

Do not press any button

MIXED : For loads including a

mixture of different types and thicknesses

of fabric (e.g cottons + resistant

synthetics) or mixed-fibre clothes

Press the MIXED button

SYNTHETICS :

For 100% synthetic

fabrics

Press the

SYNTHETICS

button

DELICATES : For delicate synthetics

and other particularly heat-sensitive

fabrics (e.g acrylic fibres)

Press the two buttons +

SELECTION OF DRYING TIME

see picture 8

➁➁

With the knob ➁ , select the required

drying time according to the type and the

load of laundry as well as to the spinning

efficiency of your washing machine.

This operation switches on your

appliance.

DRYING TIME

Recommended loads according to the

kind of the laundry are the following :

COTTON : Maximum 5 kg dry laundry

Minimum 1.5 kg dry laundry

SYNTHETIC : Maximum 2 kg dry laundry

Minimum 0.5 kg dry laundry

The drying times below include an 8- minute

cooling phase at the end of the cycle and

are given as a general indication, as they

vary according to :

- the desired result : dry, slightly damp,...

- the room temperature (the indications

correspond to 20°).

- the spinning efficiency.

For a spinning speed of 850 r.p.m. :

COTTON : 5 kg between 1h 30 and 1h 40

MIXED : 3.5 kg between 1h 30 and 1h 40

For a spinning speed of 500 r.p.m. :

MIXED : 2 kg between 50 and 60 mn.

DELICATE : 1 kg between 55 and 65 mn.

Lower spinning speeds mean relatively

longer drying times.

SWITCHING OFF

After the 8-minute coolong phase, the

knob will be in the “STOP” position.Turn it

to the off “O” position. As a precaution,

the supply cable should be disconnected.

COLD PROGRAMME

This position can be selected to freshen

clothes which have been kept for a long

time.

This programme can also be used as

supplementary drying for clothes which

have not been sufficiently dried at the end

of the normal programme.

Your machine conforms to European

Directives EC/73/23 (Low Voltage

directive) and EEC/89/336

(Electromagnetic Compatibility) as

modified by EEC/93/68.
