STAGE 6402 STAGE 8602
SPECIFICATIONS STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Type 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Coaxial Car Speaker Coaxial Car Speaker Coaxial Car Speaker Coaxial Car Speaker Three-Way Car Speaker Component System
Continuous power handling 35W 45W 35W 60W 70W 50W
Peak power handling 105W 135W 105W 180W 210W 150W
Frequency response 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Nominal impedance 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Sensitivity (2.83V/m) 91dB 91dB 90dB 91dB 92dB 90dB
External diameter 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Mounting cutout diameter 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Total depth 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Mounting depth 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
6-5/32"
(156.6mm)
5-31/32"
(151.7mm)
2"
(50.9mm)
2-1/4"
(56.9mm)
4-1/16"
(103.1mm)
3-13/16"
(96.9mm)
8-21/32"
(220mm)
7-4/16"
(184.4mm)
2-1/4"
(57mm)
2-10/16"
(66.7mm)
5-9/16"
(140.8mm)
5-1/16"
(128.4mm)
SPÉCIFICATIONS STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Type 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Haut-parleur Haut-parleur Haut-parleur Haut-parleur Haut-parleur automobile Système de
automobile coaxial automobile coaxial automobile coaxial automobile coaxial trois voies composants
Puissance admissible continue 35W 45W 35W 60W 70W 50W
Puissance admissible crête 105W 135W 105W 180W 210W 150W
Réponse en fréquence 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Impédance nominale 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Sensibilité (2.83V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Diamètre externe 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Diamètre de découpe de montage 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Profondeur totale 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Profondeur de montage 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
French
ESPECIFICACIONES STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Tipo 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Altavoz coaxial Altavoz coaxial Altavoz coaxial Altavoz coaxial Altavoz de tres vías Sistema de
para automóvil para automóvil para automóvil para automóvil para automóvil componentes
Gestión de potencia máxima continua
45W 35W 60W 70W 50W
Gestión de potencia pico 105W 135W 105W 180W 210W 150W
Intervalo de frecuencias 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Impedancia nominal 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Sensibilidad (2.83V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Diámetro externo 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Diámetro de corte para montaje 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Profundidad total 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Profundidad de montaje 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Spanish
ESPECIFICAÇÕES STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Tipo 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Alto-falante Alto-falante Alto-falante Alto-falante Alto-falante Sistema de
automotivo coaxial automotivo coaxial automotivo coaxial automotivo coaxial automotivo triaxial componentes
Potência contínua máxima 35W 45W 35W 60W 70W 50W
Potência máxima de pico 105W 135W 105W 180W 210W 150W
Resposta de frequência 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Impedância nominal 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Sensibilidade (2,83 V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Diâmetro externo 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Diâmetro do corte de montagem 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Profundidade total 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Profundidade de montagem 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Portuguese
TECHNISCHE DATEN STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Typ 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Koaxialer Koaxialer Koaxialer Koaxialer Drei-Wege- Komponentensystem
Fahrzeuglautsprecher Fahrzeuglautsprecher Fahrzeuglautsprecher Fahrzeuglautsprecher Fahrzeuglautsprecher
Kontinuierliche Leistung 35W 45W 35W 60W 70W 50W
Spitzenleistung 105W 135W 105W 180W 210W 150W
Frequenzbereich 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Nennimpedanz 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Empfindlichkeit (2.83V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Äußerer Durchmesser 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Montageausschnitt-Durchmesser 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Gesamttiefe 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Montagetiefe 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
German
SPECIFICHE STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Descrizione 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Diffusore Car Diffusore Car Diffusore Car Diffusore Car Diffusore Car Audio a tre vie Sistema a Componenti
Audio Coassiale Audio Coassiale Audio Coassiale Audio Coassiale
Tenuta in potenza continua 35W 45W 35W 60W 70W 50W
Tenuta in potenza, picco 105W 135W 105W 180W 210W 150W
Risposta in frequenza 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Impedenza nominale 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Sensibilità (2,83 V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Diametro esterno 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Diametro foro per montaggio 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Profondità totale 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Profondità di montaggio 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Italian
SPECIFICATIES STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Type 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Coaxiale Coaxiale Coaxiale Coaxiale Drie-weg autoluidspreker Componentensysteem
autoluidspreker autoluidspreker autoluidspreker autoluidspreker
Piekvermogen 35W 45W 35W 60W 70W 50W
Piekvermogen 105W 135W 105W 180W 210W 150W
Frequentiebereik 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Nominale impedantie 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Gevoeligheid (2.83V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Externe diameter 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Diameter inbouw 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Totaal diepte 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Inbouwdiepte 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Dutch
ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ
STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Тип 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Коаксиальный Коаксиальный Коаксиальный Коаксиальный Трехполосный Компонентная система
автомобильный динамик автомобильный динамик автомобильный динамик автомобильный динамик автомобильный динамик
Постоянная мощность 35W 45W 35W 60W 70W 50W
Пиковая мощность 105W 135W 105W 180W 210W 150W
Эффективный рабочий диапазон частот 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Номинальный импеданс 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Чувствительность (2,83 В/м) 91dB 91dB 90dB 91dB 92dB 90dB
Внешний диаметр 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Диаметр выемки для установки 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Общая глубина 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Глубина установки 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Russian
SPECIFIKATIONER STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Typ 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Koaxial bilhögtalare Koaxial bilhögtalare Koaxial bilhögtalare Koaxial bilhögtalare Trevägs bilhögtalare Komponentsystem
Effekt (kontinuerlig) 35W 45W 35W 60W 70W 50W
Effekt (peak) 105W 135W 105W 180W 210W 150W
Frekvensomfång 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Nominell impedans 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Känslighet (2,83 V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Ytterdiameter 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Monteringshål 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Totalt djup 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Monteringsdjup 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Swedish
DANE TECHNICZNE STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Rodzaj 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Współosiowy głośnik Współosiowy głośnik Współosiowy głośnik Współosiowy głośnik Trójdrożny głośnik Zestaw głośnikowy
samochodowy samochodowy samochodowy samochodowy samochodowy
Moc (ciągła) 35W 45W 35W 60W 70W 50W
Moc (szczytowa) 105W 135W 105W 180W 210W 150W
Pasmo przenoszenia 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Impedancja znamionowa 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Efektywność (przy 2,83 V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Średnica zewnętrzna 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Średnica wnęki do montażu 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Całkowita głębokość 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Głębokość montażowa 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Polish
사양 STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
타입 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
동축 카 스피커 동축 카 스피커 동축 카 스피커 동축 카 스피커 3방향 카 스피커 컴포넌트 시스템
연속 파워 핸들링 35W 45W 35W 60W 70W 50W
최대 파워 핸들링 105W 135W 105W 180W 210W 150W
주파수 응답 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
공칭 임피던스 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
민감도(2.83V/m) 91dB 91dB 90dB 91dB 92dB 90dB
외경 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
장착 컷아웃 직경 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
총 깊이 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
장착 깊이 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Korean
SPESIFIKASI STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Tipe 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Speaker mobil Speaker mobil Speaker mobil Speaker mobil Speaker mobil tiga fitur Sistem komponen
koaksial koaksial koaksial koaksial
Penanganan daya kontinu 35W 45W 35W 60W 70W 50W
Penanganan daya puncak 105W 135W 105W 180W 210W 150W
Respons frekuensi 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Impedansi Nomimal 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Sensitivitas (2,83V /m) 91dB 91dB 90dB 91dB 92dB 90dB
Diameter eksternal 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Diameter potongan dudukan 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Kedalaman total 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Kedalaman dudukan 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Bahasa
TEKNIK ÖZELLIKLER STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Tip 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Koaksiyel araba Koaksiyel araba Koaksiyel araba Koaksiyel araba Üç yollu araba hoparlörü Bileşen sistemi
hoparlörü hoparlörü hoparlörü hoparlörü
Sürekli güç kullanımı 35W 45W 35W 60W 70W 50W
Tepe güç kullanımı 105W 135W 105W 180W 210W 150W
Frekans yanıtı 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Nominal Empedans 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Hassasiyet (2,83V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Dış çap 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Montaj kesme çapı 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Toplam derinlik 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Montaj derinliği 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Turkish
SPESIFIKASJONER STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Type 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Koaksial bilhøyttaler Koaksial bilhøyttaler Koaksial bilhøyttaler Koaksial bilhøyttaler Tre-veis bilhøyttaler Komponentsystem
Kontinuerlig effekthåndtering 35W 45W 35W 60W 70W 50W
Toppeffekthåndtering 105W 135W 105W 180W 210W 150W
Frekvensrespons 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Nominell impedans 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Sensitivitet (2,83 V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Ekstern diameter 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Monteringsdiameter 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Totaldybde 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Monteringsdybde 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Norwegian
TEKNISET TIEDOT STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Tyyppi 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Koaksiaalinen Koaksiaalinen Koaksiaalinen Koaksiaalinen Kolmitie-autokaiutin Komponenttijärjestelmä
autokaiutin autokaiutin autokaiutin autokaiutin
Tehonkesto jatkuva 35W 45W 35W 60W 70W 50W
Tehonkesto huippu 105W 135W 105W 180W 210W 150W
Taajuusvaste 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Nimellisimpedanssi 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Herkkyys (2,83 V /m) 91dB 91dB 90dB 91dB 92dB 90dB
Ulkoinen halkaisija 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Asennusaukon halkaisija 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Kokonaissyvyys 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Asennussyvyys 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Finnish
SPECIFIKATIONER STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
Type 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
Koaksial bilhøjttaler Koaksial bilhøjttaler Koaksial bilhøjttaler Koaksial bilhøjttaler Trevejs bilhøjttaler Komponentsystem `
Kontinuerlig effekthåndtering 35W 45W 35W 60W 70W 50W
Spidsbelastning 105W 135W 105W 180W 210W 150W
Frekvensområde 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
Nominel impedans 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
Følsomhed (2,83 V/m) 91dB 91dB 90dB 91dB 92dB 90dB
Udvendig diameter 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
Diameter for monteringsudskæring 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
Samlet dybde 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
Monteringsdybde 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Danish
仕様書 STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
型 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
同軸カースピーカー 同軸カースピーカー 同軸カースピーカー 同軸カースピーカー 3ウェイ･カースピーカー コンポーネント･システム
連続許容入力 35W 45W 35W 60W 70W 50W
ピーク許容入力 105W 135W 105W 180W 210W 150W
周波数特性 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
公称インピーダンス 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
感度(2.83V/m) 91dB 91dB 90dB 91dB 92dB 90dB
外部直径 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
取り付けカットアウト直 径 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
トータルの寸法 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
埋め込み寸法 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Japanese
规格 STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
类型 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
同轴车载扬声器 同轴车载扬声器 同轴车载扬声器 同轴车载扬声器 三分频车载扬声器 分体音响系统
连续功率承受能力 35W 45W 35W 60W 70W 50W
峰值功率承受能力 105W 135W 105W 180W 210W 150W
频率响应 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
标称阻抗 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
灵敏度 (2.83V/m) 91dB 91dB 90dB 91dB 92dB 90dB
外径 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
安装切口直径 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
总深度 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
安装深度 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Simplified
Chinese
規格 STAGE 502 STAGE 602 STAGE 6402 STAGE 8602 STAGE 9603 STAGE 600C
類型 5-1/4" (130mm) 6-1/2" (165mm) 4" x 6" (102mm x 152mm) 6" x 8" (152mm x 203mm) 6" x 9" (152mm x 230mm) 6-1/2" Car Audio
同軸汽車喇叭 同軸汽車喇叭 同軸汽車喇叭 同軸汽車喇叭 三路汽車喇叭 元件系統
連續的功率處理 35W 45W 35W 60W 70W 50W
峰值的功率處理 105W 135W 105W 180W 210W 150W
頻率回應 70Hz – 20kHz 55Hz – 20kHz 75Hz – 20kHz 20Hz – 20kHz 45Hz – 20kHz 50Hz – 20kHz
標稱阻抗 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms 4 ohms
敏感度 (2.83V /m) 91dB 91dB 90dB 91dB 92dB 90dB
外徑 5-1/8" (130mm) 6-9/16" (166.4mm) 6-5/32" (156.6mm) x 8-21/32" (220mm) x 9-1/4" (234.6mm) x 6-9/16" (166.4mm)
4-1/16" (103.1mm) 5-9/16" (140.8mm) 6-7/16" (163.6mm)
安裝開孔直徑 4-3/4" (120mm) 5-12/16" (145.7mm) 5-31/32" (151.7mm) 7-4/16" (184.4mm) 8-11/16" (220.9mm) 5-12/16" (145.7mm)
總深度 2-1/2" (63.1mm) 2-10/16" (66.4mm) 2-1/4" (56.9mm) 2-10/16" (66.7mm) 3-7/16" (86.9mm) 2-10/16" (66.4mm)
安裝深度 2-3/16" (56mm) 2-5/16" (58.7mm) 2" (50.9mm) 2-1/4" (57mm) 2-29/32" (74mm) 2-5/16" (58.7mm)
Traditional
Chinese
Loading…
Định giá
Hãy cho chúng tôi biết bạn nghĩ gì về JBL Stage 502 Loa xe hơi bằng cách để lại đánh giá sản phẩm. Muốn chia sẻ trải nghiệm của bạn với sản phẩm này hoặc đặt câu hỏi? Vui lòng để lại nhận xét ở cuối trang.Thông tin thêm về hướng dẫn này
Chúng tôi hiểu rằng thật tuyệt khi có sách hướng dẫn bằng giấy cho JBL Stage 502 Loa xe hơi của bạn. Bạn luôn có thể tải xuống hướng dẫn sử dụng từ trang web của chúng tôi và tự in. Nếu bạn muốn có sách hướng dẫn gốc, chúng tôi khuyên bạn nên liên hệ với JBL. Họ có thể cung cấp hướng dẫn gốc. Bạn đang tìm kiếm hướng dẫn sử dụng JBL Stage 502 Loa xe hơi của mình bằng ngôn ngữ khác? Chọn ngôn ngữ ưa thích của bạn trên trang chủ của chúng tôi và tìm kiếm số kiểu máy để xem chúng tôi có sẵn ngôn ngữ đó không.
Thông số kỹ thuật
| Nhãn hiệu | JBL |
| Người mẫu | Stage 502 |
| Loại | Loa xe hơi |
| Loại tệp | |
| Kích thước tập tin | 1.25 MB |
Tất cả hướng dẫn sử dụng cho JBL Loa xe hơi
Thêm hướng dẫn sử dụng của Loa xe hơi
Tham gia cuộc trò chuyện về sản phẩm này
Tại đây bạn có thể chia sẻ suy nghĩ của mình về JBL Stage 502 Loa xe hơi. Nếu bạn có thắc mắc, trước tiên hãy đọc kỹ hướng dẫn. Yêu cầu một hướng dẫn có thể được thực hiện bằng cách sử dụng mẫu liên hệ của chúng tôi.
