6 | English

u Keep cutting tools sharp and clean. Properly main-

tained cutting tools with sharp cutting edges are less

likely to bind and are easier to control.

u Use the power tool, accessories and tool bits etc. in

accordance with these instructions, taking into ac-

count the working conditions and the work to be per-

formed. Use of the power tool for operations different

from those intended could result in a hazardous situation.

u Keep handles and grasping surfaces dry, clean and

free from oil and grease. Slippery handles and grasping

surfaces do not allow for safe handling and control of the

tool in unexpected situations.

Service

u Have your power tool serviced by a qualified repair

person using only identical replacement parts. This

will ensure that the safety of the power tool is maintained.

Safety Warnings for Drills

Safety instructions for all operations

u Wear ear protectors when impact drilling. Exposure to

noise can cause hearing loss.

u Use auxiliary handle(s). Loss of control can cause per-

sonal injury.

u Hold the power tool by insulated gripping surfaces,

when performing an operation where the cutting ac-

cessory or fasteners may contact hidden wiring or its

own cord. Cutting accessory or fasteners contacting a

"live" wire may make exposed metal parts of the power

tool "live" and could give the operator an electric shock.

Safety instructions when using long drill bits

u Never operate at higher speed than the maximum

speed rating of the drill bit. At higher speeds, the bit is

likely to bend if allowed to rotate freely without contact-

ing the workpiece, resulting in personal injury.

u Always start drilling at low speed and with the bit tip

in contact with the workpiece. At higher speeds, the bit

is likely to bend if allowed to rotate freely without contact-

ing the workpiece, resulting in personal injury.

u Apply pressure only in direct line with the bit and do

not apply excessive pressure.Bits can bend causing

breakage or loss of control, resulting in personal injury.

Additional safety warnings

u Switch the power tool off immediately if the applica-

tion tool becomes blocked. Be prepared for high

torque reactions which cause kickback. The applica-

tion tool becomes blocked when it becomes jammed in

the workpiece or when the power tool becomes over-

loaded.

u Hold the power tool securely. When tightening and

loosening screws be prepared for temporarily high torque

reactions.

u Secure the workpiece. A workpiece clamped with

clamping devices or in a vice is held more secure than by

hand.

u Use suitable detectors to determine if utility lines are

hidden in the work area or call the local utility com-

pany for assistance. Contact with electric lines can lead

to fire and electric shock. Damaging a gas line can lead to

explosion. Penetrating a water line causes property dam-

age or may cause an electric shock.

u Always wait until the power tool has come to a com-

plete stop before placing it down. The application tool

can jam and cause you to lose control of the power tool.

Products sold in GB only:

Your product is fitted with an BS 1363/A approved electric

plug with internal fuse (ASTA approved to BS 1362).

If the plug is not suitable for your socket outlets, it should be

cut off and an appropriate plug fitted in its place by an au-

thorised customer service agent. The replacement plug

should have the same fuse rating as the original plug.

The severed plug must be disposed of to avoid a possible

shock hazard and should never be inserted into a mains

socket elsewhere.

Product Description and

Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-

structions may result in electric shock, fire

and/or serious injury.

Please observe the illustrations at the beginning of this oper-

ating manual.

Intended Use

The power tool is intended for impact drilling in brick, con-

crete and stone, as well as for drilling in wood, metal,

ceramic and plastic. Tools with electronic control and right/

left rotation are also suitable for screwdriving and thread

cutting.

Product Features

The numbering of the product features refers to the diagram

of the power tool on the graphics page.

(1)

Keyed chuck

(2)

"Drilling/impact drilling" selector switch

(3)

Lock-on button for on/off switch

(4)

On/off switch

(5)

Rotational direction switch

(6)

Button for depth stop adjustment

(7)

Wing bolt for auxiliary handle adjustment

(8)

Auxiliary handle (insulated gripping surface)

(9)

Depth stop

(10)

Handle (insulated gripping surface)

(11)

Chuck key

(12)

Screwdriver bit

A)

1 609 92A 5E5 | (10.09.2019) Bosch Power Tools
