b)Upholstery nozzle

To vacuum upholstered furniture, curtains,

mattresses etc..

c) Furniture brush

To vacuum window frames, cupboards,

sections etc..

Illustration 10

When taking brief vacuuming pauses, you can

use the parking aid on the back of the

appliance. Push the hook on the floor nozzle

in to the recess on the back of the appliance.

Illustrations 11 + 12

When vacuuming, e.g. stairs, the appliance

can also be carried using the two grips.

After work

Illustration 13

Pull out the mains plug.

Pull briefly on the mains cable and then let go

(the cable rolls up automatically).

Illustration 14

To store / transport the appliance, you can

use the storing aid on the underside of the

appliance. Stand the appliance up straight.

Push the hook on the floor nozzle in to the

recess on the underside of the appliance.

Changing the filter

Replace the dust bag

Illustration 15

The filter change display on the lid turns

yellow.

Illustration 16 + 17

Open the lid and take it off by moving the

locking lever in the direction of the arrow.

Illustration 18

Close and remove the dust bag by pulling on

the cover clip.

Illustration 19

Insert he new dust bag in the holding fixture

up until the stop.

Illustration 20

When closing the lid, ensure that both of the

locking keys on the lid fit properly into the

recesses on the underside of the appliance.

After closing the cover, this audibly clicks into

place when pushed in the direction of the

arrow.

!

After vacuuming fine dust particles (like for

example, plaster, cement etc.), clean the

motor filter and, if necessary, replace the

microfilter.

Please fold out the picture page

Starting up

Illustration 1

a) Position the suction hose with the direction

arrow pointing upwards - lock in to the

suction opening.

b)When removing the suction hose, press

together both latches and pull out the hose.

Illustration 2

Fit together the grip and the suction pipe.

Illustration 3

Fit together the floor nozzle and the suction

pipe.

Illustration 4

a) Fit together the suction pipe.

b)by moving the adjusting head to the

direction of the arrow, releasing the telescopic

pipe and setting to the required length.

Illustration 5

Take the mains cable by the plug and pull out

the desired length and then plug in to the

mains socket.

Illustration 6

Switch on / off the vacuum cleaner by

pressing the on / off button in the direction of

the arrow.

Illustration 7

a) Set the level of suction by turning the on / off

button in the direction of the arrow.

b)The suction performance can also be

regulated by turning the secondary air

regulator in the direction of the arrow.



Secondary air opening open

 Suction reduced



Secondary air opening closed

 Maximum suction

Suction

Illustration 8

Setting the floor nozzle:



fitted carpets and carpets 



smooth floors 

Illustration 9

Vacuuming with accessories

(insert the grip or the suction pipe, depending

on requirements).

a) Corner nozzle

To vacuum in corners and joins.

enen

Please keep these instructions. If the appliance

is passed on to a third party, ensure that the

instructions are included.

Use as directed

This vacuum cleaner is intended for use in the

home and not for industrial purposes.

The vacuum cleaner must be used exclusively in

accordance with the specifications stated in

these instructions.

The manufacturer shall not be held liable for any

damages which arise from use which is not as

directed or has been caused by an incorrect

operation of the vacuum cleaner.

Therefore, please ensure that the following

information is observed and heeded!

The vacuum cleaner may only be operated

using:



original paper filters



original spare parts, accessories or optional

accessories.

The vacuum cleaner is not suitable for:



vacuuming persons or animals



vacuuming:

– small creatures (e.g. flies, spiders, ...)

– substances which can have adverse affects

on one's health or sharp-edged, hot or

red-hot substances.

– damp or liquid substances.

– easily flammable or explosive materials and

gases.

Safety information

This vacuum cleaner complies with the

recognised regulations of technology and the

relevant safety directives. We hereby confirm the

conformity with the following European

guidelines: 89/336/EEC (changed by RL

91/263/EEC, 92/31/EEC and 93/68/EEC,

72/23/EEC (changed by RL 93/68/EEC).



Connect and start up the vacuum cleaner only

in accordance with the information stipulated

on the identification plate.



Never vacuum without the paper filter.

 The appliance could get damaged!



Children may only use the vacuum cleaner

under supervision.



Do not vacuum with the nozzle and pipe near

to the head area.

 There is a danger of injury!



Do not use the mains cable to carry or

transport the vacuum cleaner.



Fully extend the power cord if the appliance is

to be used continously for several hours.



Pull on the plug in order to remove the plug

from the mains, do not pull on the cable.



Do not pull the mains cable across any sharp

edges and do not crush it in any way.



Always pull out the mains plug prior to

carrying out any work on the vacuum cleaner.



Do not use a damaged vacuum cleaner. In the

event of any fault, pull out the mains plug.



Any repair work or the replacing of spare

parts may only be carried out by the customer

services department.



Protect the vacuum cleaner from external

weather conditions, dampness and heat

sources.



Switch off the vacuum cleaner if it stops

sucking.



A retired appliance should be made

unserviceable and then disposed of in a

proper fashion.

Information regarding disposal



Packaging

The packaging protects the vacuum cleaner

from becoming damaged during

transportation. It is made of environmentally

friendly materials and can therefore be

recycled. Dispose of any unwanted packaging

at the recycling point.



Second-hand appliances

Second-hand appliances still contain many

valuable materials. Therefore, give your

second-hand appliance to your dealer or to a

recycling centre to be recycled.

Ask your dealer or your local government about

the current methods of disposal and the location

of recycling centres in your area.

!

Please observe

Only connect the appliance to a power point

which has a fuse of at least 16 A!

If the fuse trips when the appliance is

switched on, it could be that another electric

apparatus with a greater input power is being

used on the same electricity circuit.

The tripping of the fuse is avoidable if you set

the vacuum cleaner to the lowest

performance level before you switch on and

then select a greater one after the vacuum

cleaner has been switched on.
